poseutils package

Subpackages

poseutils.datasets package
- Subpackages
- Module contents

Submodules

poseutils.camera_utils module

Most of the camera functions are taken from Zhao et al. Semantic Graph Convolution

poseutils.camera_utils.camera_to_world_frame(P, R, T)

Inverse of world_to_camera_frame

Args P: Nx3 points in camera coordinates R: 3x3 Camera rotation matrix T: 3x1 Camera translation parameters Returns X_cam: Nx3 points in world coordinates

poseutils.camera_utils.load_camera_params(hf, path)

Load h36m camera parameters

Args hf: hdf5 open file with h36m cameras data path: path or key inside hf to the camera we are interested in Returns R: 3x3 Camera rotation matrix T: 3x1 Camera translation parameters f: (scalar) Camera focal length c: 2x1 Camera center k: 3x1 Camera radial distortion coefficients p: 2x1 Camera tangential distortion coefficients name: String with camera id

poseutils.camera_utils.load_cameras(bpath='cameras.h5', subjects=[1, 5, 6, 7, 8, 9, 11])

Loads the cameras of h36m

Args bpath: path to hdf5 file with h36m camera data subjects: List of ints representing the subject IDs for which cameras are requested Returns rcams: dictionary of 4 tuples per subject ID containing its camera parameters for the 4 h36m cams

poseutils.camera_utils.project_point_radial(P, R, T, f, c, k, p)

Project points from 3d to 2d using camera parameters including radial and tangential distortion

Args P: Nx3 points in world coordinates R: 3x3 Camera rotation matrix T: 3x1 Camera translation parameters f: (scalar) Camera focal length c: 2x1 Camera center k: 3x1 Camera radial distortion coefficients p: 2x1 Camera tangential distortion coefficients Returns Proj: Nx2 points in pixel space D: 1xN depth of each point in camera space radial: 1xN radial distortion per point tan: 1xN tangential distortion per point r2: 1xN squared radius of the projected points before distortion

poseutils.camera_utils.world_to_camera_frame(P, R, T)

Convert points from world to camera coordinates

Args P: Nx3 3d points in world coordinates R: 3x3 Camera rotation matrix T: 3x1 Camera translation parameters Returns X_cam: Nx3 3d points in camera coordinates

poseutils.common module

poseutils.common.calc_angle_360(v1, v2, n)

Calculates the angle within 360 degrees between two vectors $v_1$ and $v_2$ around normal $n$ .

$\vec{x} &= \vec{v_1} \cdot \vec{v_2} \\ c &= sign(\vec{x} \cdot \vec{n}) * |\vec{x}| \\ a &= \tan^{-1} \frac{c}{\vec{v_1} \cdot \vec{v_2}}$

Parameters

v1 (numpy.ndarray) – Vector Nx1 or 1xN
v2 (numpy.ndarray) – Vector Nx1 or 1xN
n (numpy.ndarray) – Vector Nx1 or 1xN

Returns

Angle in degrees

Return type

float

poseutils.common.normalize_a_to_b(a, b)

Normalizes a vector from a to b

Parameters

a (numpy.ndarray) – Start position vector
b (numpy.ndarray) – End position vector

Returns

Normalized vector from a to b

Return type

numpy.ndarray

poseutils.common.normalize_vec(vec)

Normalizes a vector to a unit vector

Parameters: vec (numpy.ndarray) – Vector to normalize (Nx1 or 1xN)
Returns: Normalized vector (Nx1 or 1xN)
Return type: numpy.ndarray

poseutils.composite module

poseutils.composite.scale_into_bounding_box_2d(joints, low=0, high=256)

Composite function to do cropping and scaling in one routine. Given an array of joint positions, it first extracts bounding box information. Then uses it to scale up/down in range [low, high] while preserving aspect ratio.

Parameters

joints (numpy.ndarray) – Positions of joints (NxMx2), where M = 14 or 16
low (int, optional) – Lowest coordinate of the bounding box, defaults to 0
high (int, optional) – Highest coordinates of the bounding box, defaults to 256

Returns

Scaled joint positions (NxMx2), where M = 14 or 16

Return type

numpy.ndarray

poseutils.constants module

poseutils.constants.NAMES_14
Edge/bone names for 14 joint configuration

poseutils.constants.NAMES_16
Edge/bone names for 16 joint configuration

poseutils.constants.EDGES_14
Edge list for 14 joint configuration

poseutils.constants.LEFTS_14
Left side indices of the skeleton for 14 joint configuration

poseutils.constants.RIGHTS_14
Right side indices of the skeleton for 14 joint configuration

poseutils.constants.EDGES_16
Edge list for 16 joint configuration

poseutils.constants.LEFTS_16
Left side indices of the skeleton for 16 joint configuration

poseutils.constants.RIGHTS_16
Right side indices of the skeleton for 16 joint configuration

poseutils.constants.EDGE_NAMES_16JNTS
Edge/bone names for 16 joint configuration

poseutils.constants.EDGE_NAMES_14JNTS
Edge/bone names for 14 joint configuration

poseutils.constants.adjacency_list(n_jnts)

Returns a adjacency list arranged in parent -> [children list] format either 14 or 16 joint configuration.

Parameters: n_jnts (int) – Number of joints, either 14 or 16
Raises: ValueError – If any other joint configuration is requested
Returns: Adjacency list (n_jnts, [])
Return type: list(list(int))

poseutils.constants.dataset_indices(dataset_name, n_jnts)

Returns either 14 or 16 joint configuration indices for specified dataset. Supports h36m, gpa, 3dpw, surreal, 3dhp. It returns indices to pick from the full dataset and rearrange them to ensure consistency.

Parameters

dataset_name (str) – Name of the dataset. Supports h36m, gpa, 3dpw, surreal, 3dhp
n_jnts (int) – Number of joint configuration to return. Either 14 or 16.

Raises

ValueError – If the dataset name provided is not supported.

Returns

to_select: List of selection indices [n_jnts]
to_sort: List of sorting order [n_jnts]

Return type

tuple(list(int), list(int))

poseutils.logger module

poseutils.logger.log(message)

Logger for packaage. Prints the string with additional information.

Parameters: message (str) – Message to print

poseutils.metrics module

poseutils.metrics.calculate_jpe(pred, target)

Given prediction and ground truth 3d position calculates joint position error.

Parameters

pred (numpy.ndarray) – Predicted 3d joint positions (NxMx3), where M = 14 or 16
target (numpy.ndarray) – Ground truth 3d joint positions (NxMx3), where M = 14 or 16

Returns

MPJPE: Mean per joint position error
PJPE: Per joint position error (Mx1)
PPJPE: Per point joint position error (Nx1)

Return type

tuple(float, numpy.ndarray, numpy.ndarray)

poseutils.props module

poseutils.props.calculate_avg_limb_lengths(jnts_xd, cvt_mm=False)

Calculates aveage edge/limb length (Euclidean distance) of a 2d or 3d skeleton.

Parameters

jnts_xd (numpy.ndarray) – Joint positions (NxMxI), M = 14 or 16, I = 2 or 3
cvt_mm (bool, optional) – Convert from meter to milimeters, defaults to False

Returns

Limb/edge lengths (M-1)

Return type

list(float)

poseutils.props.calculate_camera_angles(data)

Calculates the relative camera angles (elevation and azimuth) w.r.t. body centered axes.

$\bm{u} &= \frac{\bm{p_{ls}} + \bm{p_{rs}}}{2} - \bm{p_h} \\ \bm{\hat{u}} &= \frac{\bm{u}}{|\bm{u}|} \\ \bm{f} &= (\bm{p_{ls}} - \bm{p_h}) \times (\bm{p_{rs}} - \bm{p_h}) \\ \bm{\hat{f}} &= \frac{\bm{f}}{|\bm{f}|} \\ \bm{r} &= \bm{\hat{f}} \times \bm{\hat{u}} \\ \bm{\hat{r}} &= \frac{\bm{r}}{|\bm{r}|} \\ \bm{\hat{u}} &= \frac{\bm{\hat{r}} \times \bm{\hat{f}}}{|\bm{\hat{r}} \times \bm{\hat{f}}|} \\ \bm{c} &= - \bm{p_h} \\ e &= 90 - \frac{180}{\pi} \times (\cos^{-1}(\bm{\hat{u}} \cdot \bm{c})) \\ \bm{\hat{c_u}} &= (\bm{\hat{u}} \cdot \bm{c}) \bm{\hat{u}} \\ \bm{\hat{c_{rf}}} &= \frac{\bm{c} - \bm{c_u}}{|\bm{c} - \bm{c_u}|} \\$

Then calculate the angle around :math: bm{hat{u}}, between two vectors, $\bm{\hat{f}}$ and $\bm{\hat{c_{rf}}}$

Parameters: data (numpy.ndarray) – Joint positions (NxMx3), M = 14 or 16
Returns: Array of angles in degrees [0, 360]
Return type: numpy.ndarray

poseutils.props.calculate_limb_lengths(jnts_xd, cvt_mm=False)

Calculates every edge/limb length (Euclidean distance) of a 2d or 3d skeleton.

Parameters

jnts_xd (numpy.ndarray) – Joint positions (MxI), M = 14 or 16, I = 2 or 3
cvt_mm (bool, optional) – Convert from meter to milimeters, defaults to False

Returns

Limb/edge lengths (M-1)

Return type

list(float)

poseutils.props.get_angles_from_joints(joints)

Convert skeleton from positions to inter-joint angles

Parameters

joints (numpy.ndarray) – Joint positions (Mx3), M = 14 or 16

Raises

ValueError – If anyother joint configuration is specified

Returns

joint_angles: Inter-joint angles
edge_names: Edge/limb names

Return type

tuple(numpy.ndarray, numpy.ndarray)

poseutils.props.get_body_centered_axes(joints)

Calculates and returns body centered axes - right, up and forward vectors of the skeleton.

$\bm{u} &= \frac{\bm{p_{ls}} + \bm{p_{rs}}}{2} - \bm{p_h} \\ \bm{\hat{u}} &= \frac{\bm{u}}{|\bm{u}|} \\ \bm{f} &= (\bm{p_{ls}} - \bm{p_h}) \times (\bm{p_{rs}} - \bm{p_h}) \\ \bm{\hat{f}} &= \frac{\bm{f}}{|\bm{f}|} \\ \bm{r} &= \bm{\hat{f}} \times \bm{\hat{u}} \\ \bm{\hat{r}} &= \frac{\bm{r}}{|\bm{r}|} \\ \bm{f} &= (\bm{p_{ls}} - \bm{p_h}) \times (\bm{p_{rs}} - \bm{p_h}) \\ \bm{\hat{f}} &= \frac{\bm{f}}{|\bm{f}|} \\ R &= [\bm{\hat{r}} \; \bm{\hat{u}} \; \bm{\hat{f}}]$

Parameters

joints (numpy.ndarray) – Joint positions (NxMx3), M = 14 or 16

Returns

up: Up vectors (Nx3x1)
forward: Forward vectors (Nx3x1)
right: Right vectors (Nx3x1)
R: Rotation/set of axes matrix (Nx3x3)

Return type

tuple(numpy.ndarray, numpy.ndarray, numpy.ndarray, numpy.ndarray)

poseutils.props.get_bounding_box_2d(joints)

Get 2d bounding box

Parameters

joints (numpy.ndarray) – Joint positions (NxMx2)

Returns

left_x: Array of x coordinates of left side
left_y: Array of y coordinates of left side
right_x: Array of x coordinates of right side
right_y: Array of y coordinates of right side

Return type

tuple(numpy.ndarray, numpy.ndarray, numpy.ndarray, numpy.ndarray)

poseutils.props.get_joints_from_angles(angles, bone_lengths)

Convert inter-joint angles to positions

Parameters

angles (numpy.ndarray) – Array of angles in degrees (M-1)x3
bone_lengths (numpy.ndarray) – Array of bone lengths (M-1)x1

Raises

ValueError – If anyother joint configuration is specified

Returns

Joint positions (Mx3), root centered

Return type

numpy.ndarray

poseutils.transform module

poseutils.transform.normalize_skeleton(joints)

Normalizes joint positions (NxMx2 or NxMx3, where M is 14 or 16) from parent to child order. Each vector from parent to child is normalized with respect to it’s length.

Parameters: joints (numpy.ndarray) – Position of joints (NxMx2) or (NxMx3)
Returns: Normalzed position of joints (NxMx2) or (NxMx3)
Return type: numpy.ndarray

poseutils.transform.normalize_torso_2d(torso)

Takes in the torso coordinates and normalizes it. Takes the distance of each torso joint from the Right Hip joint position. Each distance is then normalized with the distance along the diagonal connecting Right Hip to Left Shoulder. A small value is added to the diagonal distance to avoid divide-by-zero error.

Parameters

torso (numpy.ndarray) – Torso joint positions (Nx4x2), with arranged in order: Right Hip, Left Hip, Left Shoulder, Right Shoulder

Returns

New torso positions (Nx4x2)
Width of right hip to left hip, right hip to left shoulder, right hip to right shoulder (Nx3)
List of names of the widths

Return type

tuple(numpy.narray, numpy.ndarray, list(str))

poseutils.transform.normalize_zscore(X, mean, std, skip_root=False)

Normalize position of joints using z-score normalization. Subtracts mean and divides by standard devation. Metrics are ideally collected from the training set.

Parameters

X (numpy.ndarray) – Position of joints (NxMx2) or (NxMx3)
mean (numpy.ndarray) – Mean joint position (Mx2) or (Mx3)
std ([type]) – Standard deviation of joint positions (Mx2) or (Mx3)
skip_root (bool, optional) – Whether to skip over the root/hip when normalizing, defaults to False

Returns

New position of joints (NxMx2) or (NxMx3)

Return type

numpy.ndarray

poseutils.transform.root_center(X, root_idx=0)

Subtract the value at root index to make the coordinates center around root. Useful for hip-centering the skeleton.

Parameters

X (numpy.ndarray) – Position of joints (NxMx2) or (NxMx3)
root_idx (int, optional) – Root/Hip index, defaults to 0

Returns

New position of joints (NxMx2) or (NxMx3)

Return type

numpy.ndarray

poseutils.transform.scale_bounding_area_to(X, bbox, low=0, high=256)

Scales up or down the bounding box enclosed region to fit in a (high-low) sided square while preserving aspect ratio.

Parameters

X (numpy.ndarray) – Position of joints (NxMx2)
bbox (numpy.ndarray) – Bounding box coordinates (Nx4) where columns are stacked as [lx, ly, rx, ry]. (lx, ly) is the coordinate for top-left corner whereas (rx, ry) is the coordinate of the bottom-right corner
low (int, optional) – Lowest value of the bounding box, defaults to 0
high (int, optional) – Highest value of the bounding box, defaults to 256

Returns

New position of joints (NxMx2)

Return type

numpy.ndarray

poseutils.transform.unnormalize_zscore(X, mean, std, skip_root=False)

Reverses normalized position of joints using z-score normalization. Multiplies by standard devation and adds the mean. Metrics are ideally collected from the training set.

Parameters

X (numpy.ndarray) – Position of joints (NxMx2) or (NxMx3)
mean (numpy.ndarray) – Mean joint position (Mx2) or (Mx3)
std ([type]) – Standard deviation of joint positions (Mx2) or (Mx3)
skip_root (bool, optional) – Whether to skip over the root/hip when unnormalizing, defaults to False

Returns

New position of joints (NxMx2) or (NxMx3)

Return type

numpy.ndarray

poseutils.view module

poseutils.view.draw_axes(R, t, ax, scale=0.5)

Draw xyz axes centered at a position.

Parameters

R (numpy.ndarray) – Rotation matrix (3,3) with columns representing xyz columns respectively
t (numpy.ndarray) – Position t (3,) acting as the origin of the xyz axes
ax (matplotlib.pyplot.subplot) – Matplotlib subplot reference
scale (float, optional) – To scale up the axes, defaults to 0.5

poseutils.view.draw_bounding_box(lx, ly, rx, ry, ax)

Draws bounding box

Parameters

lx (numpy.ndarray) – X coordinates (Nx1) for top-left corner of the box
ly (numpy.ndarray) – Y coordinates (Nx1) for top-left corner of the box
rx (numpy.ndarray) – X coordinates (Nx1) for bottom-right corner of the box
ry (numpy.ndarray) – Y coordinates (Nx1) for bottom-right corner of the box
ax (matplotlib.pyplot.subplot) – Matplotlib subplot reference

poseutils.view.draw_skeleton(pose, ax, jnts_14=True)

Draws a skeleton from joints

Parameters

pose (numpy.ndarray) – Joint positions either 2d (Nx2) or 3d (Nx3) where N = 14 or 16
ax (matplotlib.pyplot.subplot) – Matplotlib subplot reference
jnts_14 (bool, optional) – Flag to specify whether to use 14 joint (True) or 16 joint (False) configuration, defaults to True

poseutils package

Subpackages

Submodules

poseutils.camera_utils module

poseutils.common module

poseutils.composite module

poseutils.constants module

poseutils.logger module

poseutils.metrics module

poseutils.props module

poseutils.transform module

poseutils.view module

Module contents
